The Material Works, Ltd.

This ISO-9001:2000 certified toll processor handles everything from light gauge to heavy gauge and from aluminum to hot roll. Our total 306,000 sq. ft. of plant space is all climate controlled, features direct barge and rail unloading without touching a truck, and offers a full range of processing capabilities.

TMW also offers comprehensive downstream supply chain management services including coil optimizations to reduce scrap, inventory management, production planning, in-plant cost savings help, and return skid programs.

101 South Main Street
Red Bud, Illinois 62278
Tel: 618-282-4200
Fax: 618-282-4201

CAPABILITY	Material	Inbound Size	Thickness	Accuracy/Other
SCS Sheet Line	Hot Roll Black	to 74" W x 276" L	0.043" to 0.500"	max. sheet weight 1000 lbs.
Stretcher Leveling CTL	Any Material	to 84"OD x 74" W	0.010" to 0.375"	+/-0.005" for parts up to 500"
Slitting	All but HR Black	to 84"OD x 80" W	0.010" to 0.250"	+/-0.005" width / trim to 2.75"
Multi-Cut Blanking	Any Material	to 84"OD x 74" W	0.010" to 0.135"	+/-0.005" for parts up to 240"
Cut-To-Length	Any Material	to 84"OD x 74" W	0.010" to 0.312"	+/-0.005" for parts up to 480"
Fabrication Services	Laser Cutting – Turret Punching – Shears –	to 60" W x 120 " L to 60" W x 120 " L width 1" to 120"	to 0.750" to 0.250" 0.20" to 0.375"	to +/-0.015" / 4000 watt laser to +/-0.006" / 33 tons force to +/-0.031" / 5000 lb. stack
